Back Bolt Fixture Plate Workflow

A 3-step diagram showing the McChine 'Picture Framing' workflow, with text labels for each stage: prepping the stock, mounting on the fixture plate, and the finished part ready for removal.

Setup 1 End

1. Prep Your Stock Machine the mounting holes and "picture frame" pocket into the back of your raw material while it's held in a standard vise.

Setup 2 Start

2. Mount & Machine Bolt the prepped stock to the fixture plate. This bottom-up workholding gives you complete, unobstructed access to machine the top and sides of your part.

Setup 2 End

3. Finish & Remove Machine the final profile. Once done, simply remove the part from the plate and break the small tabs to release your finished piece.

Ready to Revolutionize Your Workholding?

Shop Fixture Plates

Tired of Traditional Workholding Hassles?

  • Wasted Time & Material

    Stop creating one-off soft jaws for every job.

  • Clamp Interference

    Eliminate the need to program complex toolpaths to avoid top clamps.

  • Part Warping

    Prevent inaccuracies caused by excessive vise pressure.

Quality You Can Trust.

  • CNC milling machine icon

    Designed by a Machinist

    Our fixtures are designed with 30 years of machining experience to solve the real-world workholding problems you face every day.

  • Made in the USA

    Made in the USA

    All of our products are proudly designed, manufactured, and shipped from our shop in Mt. Juliet, Tennessee.

  • McChine Product Warranty

    Limited Lifetime Warranty

    We stand behind our quality. Every fixture plate is backed by our lifetime warranty against any defects in materials or workmanship.
